Ray Mini

SKU:
ray_mini
Brand:
Archilight
Unit of Measure:
item
Warranty Period:
5 year
Power Input:
230V AC
Power Rating:
3 W
Dimming Control:
Optional
Colour Rendering Index:
90
Driver Included:
Driver Included
Series:
Archilight Ray Mini Series
Material:
Aluminium
Waterproof:
IP20
Standards Met:
CB, CCC, CE, SAA, TUV
Operating Temperature:
-25°C~50°C
Dimensions:
Height:57mm | Diameter:40mm
Cut-out Size:
35mm
Mounting:
Recessed
Lifetime:
50000 h
Beam Angle:
25 Degree
Finish Colour:
Black and Black, White and White, White and Black, White and Gray, White and Gold, White and Red, White and Silver
LED Colour:
Warm White 3000K, Warm White 2700K, Natural White 4000K

The Ray series is a stylish, and compact downlight series that offers a wide variety of colour options with a very small trim for that minimalist look. Its power efficient design with high colour rendering index (CRI>90) and low UGR rating (UGR<19) makes it a top quality light with low glare to provide high visual comfort, whilst displaying the true colours of an area beautifully. With a wide variety of colour, size and beam options available, the Ray series is perfect for all uses, from general lighting to accent lighting to highlight the important features in your project.
